Product Specifications :
- Active Membrane Area : 85 ft² (7.9 m²)
- Permeate Flow Rate : 2,500 gpd (9.5 m³/d)
- Stabilized Salt Rejection : 99.6%
- Minimum Salt Rejection : 99.3%
Test Conditions :
- NaCl : 2,000 ppm
- Pressure : 225 psi (15.5 bar)
- Temperature : 25°C (77°F)
- pH : 8
- Recovery : 15%
- Permeate Flow Variation : +/-20%
Operating Specifications :
- Max. Operating Pressure : 600 psi (41 bar)
- Max. Chlorine Concentration : < 0,1 ppm
- Max. Operating Temperature : 45°C (113°F)
- pH Range, Continuous (Cleaning) : 2-11 (2-12)
- Max. Feedwater Turbidity : 1.0 NTU
- Max. Feedwater SDI (15 minutes) : 5.0
- Max. Feed Flow : 16 gpm (3.6 m³/h)
- Max. Pressure Drop for Each Element : 15 psi (1.0 bar)
Product Dimensions :
- Length : 1,016 mm (40 inch)
- Element O.D. : 100 mm (3.9 inch)
- Permeate Tube O.D. : 19 mm (0.75 inch)
- Active Membrane Area : 85 ft² (7.9 m²)
- Weight : 3.6 kg (8.0 lbs.)
- Core Tube Extension : 28 mm (1.1 inch)
